Pivot doors to 5.5 metres, engineered per project.
Single-leaf openings to 2.5 m wide × 5.5 m high (8'2" × 18'0"), rotating on a central pivot: large glazed panels in lightweight thermally broken aluminum frames, made in Europe and configured to your drawings for projects in New York and the Caribbean.
What the pivot system does.
Pivot
The leaf turns on a central pivot rather than side hinges, so the frame carries far larger and heavier panels than a hinged entrance door. Profiles are thermally broken with a 16 mm (5/8") barrier and use a Eurogroove hardware channel, so compatible fittings can be specified per project.
System characteristics
- Leaf size: to 2.5 m wide × 5.5 m high (8'2" × 18'0"), to 450 kg (990 lb).
- Frame: depth 115 mm (4½"), continuous threshold of 7 mm (¼").
- Double leaves: openings to 4 m (13'1") across.
- Finish: any RAL color, anodized, wood finish, or dual-color inside and out.
- Hardware: integrated locking and access control specified with the leaf.
Six named door faces.
Cyrus
Mirrored glass face.
Luther
Shield-form plate.
Lucas
See-through glass.
Jesse
Real onyx with LED.
Hector
Distressed aluminum.
Keith
Wood veneer.
Faces are made to the project drawing; the six designs above are the manufacturer's named starting points.
Send us the drawings. We configure and quote per project.
Opening sizes, elevations, glazing spec if decided, and the site. Every pivot door is configured to the project.
